Pickup For TIME322X Roughness Tester

Penguji kekasaran seri TIME322X dilengkapi dengan beberapa pickup opsional yang sesuai untuk aplikasi yang berbeda.

Description

TIME S201 (standard)
Radius for needle point: 5μm
Angle for needle: 90°
Force for needle: 4mN
Measuring range: 400μm

TIME S212 for deep groove
Radius for needle point: 5μm
Angle for needle: 90°
Force for needle: 4mN
Measuring range: 400μm
Min. width of groove: 2.5mm
Max. depth of groove: 10mm

TIME S214 for curved surface
Radius for needle point: 5μm
Angle for needle: 90°
Force for needle: 4mN
Measuring range: 200μm

TIME S211 for small hole
Radius for needle point: 5μm
Angle for needle: 90°
Force for needle: 4mN
Measuring range: 100μm
Min. diameter of hole: ø2mm
Max. depth of hole: 13.5mm

TIME S213 pick up for deep hole
Radius for needle point: 5μm
Angle for needle: 90°
Force for needle: 4mN
Measuring range: 400μm
Min. width of hole: ø2mm
Max. depth of hole: 20mm

TIME S220 “O” type pick up
Radius for needle point: 5μm
Angle for needle: 90°
Force for needle: 4mN
Measuring range: 200μm
Thickness of lead head: 1mm
